Coarse npuas Diffuser SSDA12
Tau txais cov ntaub ntawv hais txog Coarse Bubble Diffuser SSDA12
Coarse npuas Diffuser SSDA12yog qhov tsim tshiab los ntawm MBBR txog kev kho dej, peb niaj hnub tsim cov khoom tshiab los sib tw nrog kev lag luam tib yam, thiab ntau txoj hauv kev peb tau teeb tsa ib ntu nrog cov ncauj lus kom ntxaws cov khoom siv rau kev siv los pab peb cov neeg siv khoom txuag lub sijhawm.
Coarse npuas Diffuser SSDA12Paub meej:
1.Nws yog ua los ntawm cov hlau tsis muaj steel Cov coarse npuas diffuser muab qhov siab tshaj plaws aeration thiab kev sib xyaw ua haujlwm. Tus qauv ntev ntawm diffuser yog 600 mm. Lub 600mm ntev diffuser tuaj yeem ua tiav 1250mm huab cua tso tawm ncig.
2. Vim tias peb siv stainless hlau, ntau tus neeg siv khoom tsis tas yuav txhawj xeeb txog qhov zoo ntawm cov khoom vim cov khoom siv. Hais txog aeration, peb siv cov tshuaj no los daws qhov teeb meem ntawm qhov chaw seem ntawm hneev taw. Nyob nruab nrab ntawm txhua ntu ntawm cov khoom peb teeb tsa ib qho tshwj xeeb articulation, lub hom phiaj yog los daws qhov teeb meem ntawm solidity ntawm cov kav dej, thiab cov kav dej ib leeg tuaj yeem tswj tau, koj tuaj yeem ntseeg tau cov qauv zoo li no.
3.Rau qhov ua tau zoo, ntau qhov chaw aeration efficiency yuav tsum tau tsim. Tshwj xeeb tshaj yog rau cov nroj tsuag loj, cov pas dej loj, koj xav tau cov tshuaj zoo thiab zoo los txhim kho cov pa oxygenation hauv cov txheej txheem MBBR.
TAG:
Cov ntsiab lus ntxiv tuaj yeem nrhiav pom raws li cov duab. Peb yeej tsis sloppy nyob rau hauv peb kev ua hauj lwm, thiab los ntawm kev noj cov tshuaj zoo li peb, koj yuav tau txais kev pab cuam tom qab muag uas kav mus txog rau 2 xyoos.
Yog tias koj muaj kev xav tau ntau tshaj li qhov ntawd, koj tuaj yeem tiv tauj peb txhua lub sijhawm los ntawm kev tau txais cov ntaub ntawv tiv tauj ntawm peb lub vev xaib thiab peb yuav muab cov lus tsim nyog rau koj raws li koj xav tau.
Tsis muaj kev daws teeb meem yuav zoo tag nrho, thiab tom qab koj tau xaiv ib qho ntawm peb cov kev daws teeb meem zoo, peb pab pawg zoo yuav txuas ntxiv mus.
Tuam txhab Taw Qhia:
Hangzhou Plastic Products Co. Ltd., tau tsim nyob rau hauv 2013 thiab peb yog lub hom phiaj los muab cov khoom yas zoo rau kev kho dej. Peb tsim Anhui Technology Co., Ltd hauv Anhui xyoo 2016. Raws li tus neeg muag khoom thiab chaw tsim khoom rau Disc diffuser, Tube diffuser, MBBR Bio Filter Media, PVC profiles thiab lwm yam khoom yas rau kev kho dej, peb yeej lub teb chaws high-tech enterprise hauv 2019 thiab muaj 35 patents.
Peb muaj 21000 square meter Hoobkas hauv Yuexi Anhui; 105 tag nrho tsis siv neeg MBBR cov kab ntau lawm, 7 kab ntawm Tube settlers, thiab 15 kab txhaj tshuaj rau Disc thiab Tube diffusers. Kev xa tawm txhua xyoo ntawm MBBR thiab cov neeg nyob hauv lub raj yog 100 000 cubic meters; txhua xyoo export ntawm diffuser thiab PVC profiles yog 5000tons. Peb tau dhau qee daim ntawv pov thawj, raws li ISO9001-2015, SGS, ROHS, FDA tus qauv khoom. Feem ntau ntawm cov khoom yog vented rau Canada, Mexico, Guatemala, Argentina, Fabkis, Lub Netherlands, Sweden, Ltalis, Taiwan Tuam Tshoj, thiab lwm yam. Lub xyoo muag yog $ 15 lab.
Peb tau cog lus los ua ib lub lag luam loj loj, koom nrog MBBR muab tub lim ntau lawm, kev muag khoom, thiab kev pab tswv yim tsim kho dej. Lub Earator diffuser thiab MBBR thev naus laus zis tau siv dav hauv Kev Kho Dej thiab hauv nroog; recirculation aquaculture system (RAS), thiab lwm yam kev kho dej ua ntaub ntawv. Peb muaj cov kws tshaj lij ib puag ncig engineers ntawm 20 xyoo kev paub, koom tes nrog ntau lub tsev kawm ntawv qib siab hauv tsev los xyuas kom zoo thaum ua kom muaj kev pabcuam zoo dua. Peb tau txais kev lees paub thiab kev ntseeg siab los ntawm peb cov neeg siv khoom, peb hais kom tsim kom muaj kev ua haujlwm nrog qhov tseeb, yeej nrog kev ua tau zoo, thiab kev sib raug zoo nrog lub siab dawb paug. Peb tos ntsoov yuav koom tes nrog koj!
Kev teeb tsa Ecuam tshuam:
 |
Layout nyob rau hauv qhov chaw txwv, |
|
Vim hais tias tus qauv architecture yog teem kuj tsim nyog, |
 |
Khoom Paub meej:
Kev teeb tsa khoom
Khoom Parameters:
|
Hom Diffuser |
Diffuser Ntev |
Tsim Huab cua |
Net Kev Ua Haujlwm Buoyancy |
Qhov Chaw |
|||
|
|
nti |
mm |
Scfm |
m3N/h |
ib lb |
kg |
mm |
|
TIAB SA 12 |
12 |
300 |
0-28 |
0-48 |
2.12 |
0.96 |
3-6 |
|
SWB 12 |
12 |
300 |
0-26 |
0-44 |
2.0 |
0.91 |
3-6 |
|
TIAB SA 24 |
24 |
600 |
0-51 |
0-87 |
4.19 |
1.9 |
3-6 |
|
SWB 24 |
24 |
600 |
0-41 |
0-80 |
4.0 |
1.82 |
3-6 |
DWP (Dynamic khib fais fab) nkhaus
OTE (Oxygen Transfer Efficiency) Curve
Cov ntaub ntawv ua haujlwm:
|
- tus nqi
|
Cua load perdiffuser element
|
Rov qab siab ntawm lub diffuser
|
Oxygenation Efficiency SOTE
|
|
0.7~0.9
|
10~50m³/h
|
5 ~ 20 hli
|
2 ~ 3% / m (cov dej huv)
3 ~ 5% / m (30% ~ 50% media sau tus nqi)
|
Daim Ntawv Thov Scope:
Main Dej Kho Yas Qhov Chaw
|
1. MBBR Media 2. Tube Settlement 3. MBR Membrane 4. Spong Bio Media 5. Disc Diffuser 6. Tube Diffuser 7. RO Water Cog 8. MBBR Mixing 9. Ro Antiscalant |
|
FAQ:
Q: Koj puas yog tuam txhab lag luam lossis chaw tsim khoom?
A: Peb muaj ob lub Hoobkas thiab tuam txhab lag luam.
Q: Koj puas tuaj yeem ua tau raws li kuv cov kev xav tau rau kev tsim khoom?
A: Yog lawm, peb muaj pab pawg tsim qauv tsim. Peb tuaj yeem muab cov duab kos thiab tsim qauv raws li koj xav tau.
Q: Yuav ua li cas rau nruab?
A: Peb yuav muab cov duab qhia ntxaws rau koj.
Yog tias tsim nyog, peb yuav xa cov kws tshaj lij los pab koj.
Txawm li cas los xij, tus nqi vixaj, daim pib dav hlau, chaw nyob, nyiaj ua haujlwm yuav raug them los ntawm cov neeg yuav khoom.
Q: Dab tsi yog koj lub peev xwm ntau lawm rau ib hlis?
A: Peb tuaj yeem tsim 2000m3 rau mbbr media rau ib hlis.Thiab 200 teeb rau kev kho dej khib nyiab kho tshuab.
Q: Koj cov nqe lus them nqi yog dab tsi?
A: Peb feem ntau siv T / T raws li txoj kev them nyiaj, 30% kev them nyiaj ua ntej thiab 70% tshuav nyiaj them ua ntej xa khoom, rau kev hloov kho, peb kuj siv txoj kev no.
Rau cov neeg yuav khoom ntev, peb tuaj yeem xaiv txoj kev them nyiaj tshwj xeeb.
Q:Dab tsi yog MOQ?
A: 100 USD rau 1 daim, Thov hu rau peb yog tias koj muaj kev xav tau tshwj xeeb.
Cim npe nrov: coarse npuas disc diffuser, Tuam Tshoj, lwm tus neeg, manufacturers, hoobkas, pheej yig, Tshuag, dawb qauv
